TPS65910A3A1RSLRG4  Battery management products Integrated Power Management IC (PMIC) w/ 4 DC/DCs, 8 LDOs and RTC in 6x6mm QFN Family 48VQFN 40 to 85
  |  3 orders
Price
US $1.80 / PCS
Shipping
-->Arrival time 5-7 days
---->Arrival time 15-27 days
-->Arrival time 5-7 days
Quantity
 PCS
Parts Amount
US $1.80

Choose us! Escort for your needs!!!^_^
Power management
Product Details
Part no.TPS65910A3A1RSLRG4
Packge/CaseVQFN48
ManutacturerTI
DescriptionBattery management products Integrated Power Management IC (PMIC) w/ 4 DC/DCs, 8 LDOs and RTC in 6x6mm QFN Family 48-VQFN -40 to 85
 DatasheetCheck Datasheet

TPS65910A3A1RSLR Datasheet, PDF

Electronic Manufacturer Part no Datasheet Electronics Description
Texas Instruments
Texas Instruments
TPS65910A3A1RSLR [Old version datasheet] Integrated Power Management Unit Top Specification
TPS65910A3A1RSLR [Old version datasheet] Integrated Power Management Unit Top Specification
Texas Instruments
Texas Instruments
TPS65910A31A1RSLR [Old version datasheet] Integrated Power Management Unit Top Specification
TPS65910A31A1RSLT [Old version datasheet] Integrated Power Management Unit Top Specification
TPS65910A3A1RSL [Old version datasheet] Integrated Power Management Unit Top Specification
TPS65910A3A1RSL [Old version datasheet] Integrated Power Management Unit Top Specification


TPS65910A3A1RSLR Datasheet, PDF More

Texas Instruments TPS65910A3A1RSLR

The TPS65910 device is an integrated power-management IC available in 48-QFN package and dedicated to applications powered by one Li-Ion or Li-Ion polymer battery cell or 3-series Ni-MH cells, or by a 5-V input; it requires multiple power rails. The device provides three step-down converters, one step-up converter, and eight LDOs and is designed to support the specific power requirements of OMAP-based applications.

Two of the step-down converters provide power for dual processor cores and are controllable by a dedicated class-3 SmartReflex interface for optimum power savings. The third converter provides power for the I/Os and memory in the system.

The device includes eight general-purpose LDOs providing a wide range of voltage and current capabilities. The LDOs are fully controllable by the I2C interface. The use of the LDOs is flexible; they are intended to be used as follows: Two LDOs are designated to power the PLL and video DAC supply rails on the OMAP-based processors, four general-purpose auxiliary LDOs are available to provide power to other devices in the system, and two LDOs are provided to power DDR memory supplies in applications requiring these memories.

In addition to the power resources, the device contains an embedded power controller (EPC) to manage the power sequencing requirements of the OMAP systems and an RTC.

View datasheet
View product folder

 的tps65910装置是一个集成的电源管理IC可在48-qfn包和致力于的一个Li Ion或Li Ion的聚合物电池或镍氢电池供电应用的3系列,或由一个5V输入;它需要多个电源轨。该器件提供三降压转换器,一个升压转换器和LDO和八,目的是支持的应用程序特定的电源要求。
两降压转换器提供双处理器内核电源和可控的专用三级smartreflex界面优化的功率节省。第三转换器为系统中的I/O和内存提供电源。
该装置包括八个通用LDO提供宽范围的电压和电流的能力。LDO是完全可控的I2C接口。该LDO使用灵活;他们的目的是要使用如下:两LDO是指定功率PLL视频DAC的电源轨基于OMAP四处理器,通用辅助LDO可在系统中的其他设备提供电源,和两个LDO在需要这些记忆的应用提供动力DDR内存供给。
除了电力资源,该器件包含一个嵌入式电源控制器(EPC)控制电源排序要求的OMAP系统和RTC。

$ 1.80 (USD)/PCS
$ 1.80 (USD)/PCS
Buyer comment area ^_^
 德*****  Order Number: PO:********1106873#
2018/3/8 11:31:10(time)
 TPS65910A3A1RSL|TPS65910A3A1RSLR|TPS65910A3A1RSLRG4|
 买家没有评价,系统默认好评。

 深*****  Order Number: PO:********6544652#
2017/10/27 17:36:54(time)
 TPS65910A3A1RSLRG4|TPS65910A3A1RSLR|
 买家没有评价,系统默认好评。

 ******  Order Number: PO:********5362492#
2017/10/23 12:25:36(time)
 TPS65910A3A1RSLRG4|TPS65910A3A1RSLR|
 买家没有评价,系统默认好评。
