Part no.TPS55340PWPR
Packge/Case14-HTSSOP
ManutacturerTexas Instruments
Description开关稳压器 Int 5-A 40-V Wide Input Rg DCDC Cnvrtr
 DatasheetCheck Datasheet

TPS55340PWPR Datasheet, PDF

Electronic Manufacturer Part no Datasheet Electronics Description
Texas Instruments
Texas Instruments
TPS55340PWPR [Old version datasheet] Integrated 5-A 40-V Wide Input Range Boost/SEPIC/Flyback DC-DC Regulator
Texas Instruments
Texas Instruments
TPS55340-EP [Old version datasheet] TPS55340-EP Integrated 5-A, 40-V Wide Input Range Boost/SEPIC/Flyback DC-DC Regulator
TPS55340-EP [Old version datasheet] Integrated 5-A, Wide Input Range Boost, SEPIC, or Flyback DC-DC Converter
TPS55340-EP_15 [Old version datasheet] TPS55340-EP Integrated 5-A, 40-V Wide Input Range Boost/SEPIC/Flyback DC-DC Regulator
TPS55340-Q1 [Old version datasheet] TPS55340-EP Integrated 5-A, 40-V Wide Input Range Boost/SEPIC/Flyback DC-DC Regulator
TPS55340-Q1 [Old version datasheet] Integrated 5-A, Wide Input Range Boost, SEPIC, or Flyback DC-DC Converter
TPS55340-Q1_15 [Old version datasheet] TPS55340-Q1 Integrated 5-A, Wide Input Range Boost, SEPIC, or Flyback DC-DC Regulator
TPS55340-Q1_16 [Old version datasheet] Integrated 5-A, Wide Input Range Boost, SEPIC, or Flyback DC-DC Converter
TPS55340EVM-017 [Old version datasheet] TPS55340EVM-017, 5-V to 12-V Input, 24-V Output Boost Evaluation Module
TPS55340EVM-147 [Old version datasheet] TPS55340EVM-147, 6V to 18V Input, 12V Output SEPIC Evaluation Module


TPS55340PWPR Datasheet, PDF More

Texas Instruments TPS55340PWPR

The TPS55340 is a monolithic, nonsynchronous, switching regulator with integrated 5-A, 40-V power switch. The device can be configured in several standard switching-regulator topologies, including boost, SEPIC, and isolated flyback. The device has a wide input voltage range to support applications with input voltage from multicell batteries or regulated 3.3-V, 5-V, 12-V, and 24-V power rails.

The TPS55340 regulates the output voltage with current mode PWM (pulse width modulation) control, and has an internal oscillator. The switching frequency of PWM is set by either an external resistor or by synchronizing to an external clock signal. The user can program the switching frequency from 100 kHz to 1.2 MHz.

The device features a programmable soft-start function to limit inrush current during start-up and has other built-in protection features including cycle-by-cycle overcurrent limit and thermal shutdown.

The TPS55340 is available in a small 3-mm × 3-mm 16-pin QFN as well as 14-pin HTSSOP packages with PowerPAD for enhanced thermal performance.

The 5-A, 40-V TPS55340 boost converter in the HTSSOP-14 package is pin-to-pin compatible with the 3-A, 40-V TPS61175 and it extends the maximum input voltage from 18 V to 32 V.

View datasheet
View product folder

德克萨斯仪器tps55340pwpr
的tps55340是单片,不同步,集成了5开关稳压器,40-V电源开关。该设备可以配置在几个标准的开关电源拓扑结构,包括升压,SEPIC和反激式隔离。该装置具有宽输入电压范围内支持应用与多单元电池输入电压3.3V或5V,12V的,调节,和24V电源轨。
的tps55340调节输出电压和电流模式PWM(脉宽调制)控制,并具有内部振荡器。PWM的开关频率是由外部电阻或同步到外部时钟信号来设置的。用户可以编程的开关频率从100千赫到1.2兆赫。
该器件具有可编程软启动功能,以限制浪涌电流在启动过程中,并具有其他内置保护功能,包括逐周期过流限制和热关机。
可在一个小型的tps55340 3mm×3毫米16引脚QFN和14引脚HTSSOP封装热性能与增强PowerPAD。
第5,tps55340 40-V Boost变换器在htssop-14封装引脚与3-A兼容,tps61175 40-V并延伸,最大输入电压从18 V到32 V。
